| Akku |
Removable Integrated Li-Ion | 480 Wh |
| Akku Hersteller |
Rocky Mountain |
| Akku Kapazität in Wh |
480 Wh |
| Akku Montage |
Intube-Akku |
| Ausstattung |
Keine Ausstattung |
| Bereifung |
Maxxis Rekon 2.4 WT EXO Tubeless Ready |
| Bremse hinten |
Shimano MT4100 2 Piston | Resin Pads |
| Bremse vorne |
Shimano MT4100 2 Piston | Resin Pads |
| Bremshebel |
Shimano MT4100 |
| Bremsscheibe |
F: Shimano RT30 203mm // R: Shimano RT30 180mm |
| Cassette |
Shimano Deore 10-51T 12spd |
| Display |
Rocky Mountain Jumbotron | Drive System Customization | Battery & Assist Level | Trip | Speed | Cadence | Top Tube Integration |
| Farbe |
Black Dog / Highway To Hell / Flaming Lips |
| Federweg vorne |
120 mm |
| Felgen |
WTB ST i30 TCS 2.0 Tubeless | 32H |
| Gabel |
RockShox Recon Gold RL 29 = 120mm 42mm Offset |
| Griffe |
Rocky Mountain Lock On Light |
| Hersteller/Marke |
Rocky Mountain |
| Kette |
Shimano M6100 |
| Kurbelgarnitur |
Race Face Ride Cinch | 34T | 24mm Spindle | 170mm Crank Length |
| Ladegerät |
Rocky Mountain Powerplay FAST Charger | 4A | 48V | Higo Deep Socket Connector | Overtimepack Compatible (Dyname 4) |
| Laufradgröße |
29 Zoll |
| Lenker |
Rocky Mountain XC | 760mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp |
| Modelljahr |
2024 |
| Motor Hersteller |
Dyname |
| Motor Leistung |
250 Watt |
| Motor Modell |
Dyname 4.0 Mountain Bike Drive | 250w Nominal Power | 108Nm | Rocky Mountain Micro Remote | Low RPM - High Efficiency class 1 eMTB System | Designed in Canada |
| Nabe hinten |
Shimano MT410 Boost 148mm |
| Nabe vorne |
Shimano MT410 | 15mm Boost |
| Pedale |
Alloy Platform |
| Produktgewicht |
22,2 kg |
| Rahmen |
FORM™ Alloy | Press Fit BB | Internal Cable Routing | Boost 148mm | Tapered Zerostack Headtube | Dropper Post Compatible |
| Rahmenmaterial |
Aluminium |
| Rahmentyp |
Diamant |
| Sattel |
WTB Volt 142 |
| Sattelstütze |
Rocky Mountain Toonie Drop Composire 30.9mm | XS = 100mm | SM = 100mm | MD = 125mm | LG - XL = 150mm |
| Schalthebel |
Shimano Deore 12spd |
| Schaltung |
Shimano Deore |
| Schaltungsart |
12 Gang Kettenschaltung |
| Schaltwerk |
Shimano SLX |
| Speichen |
2.0 Stainless |
| Steuersatz |
FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
| Vorbau |
Rocky Mountain 31.8 XC | 7° Rise | All Sizes = 50mm |
