| Akku |
Bosch DualBattery system, 500 Wh or 1000 Wh |
| Akku Hersteller |
Bosch |
| Akku Kapazität in Wh |
500 Wh |
| Akku Montage |
Gepäckträger-Akku |
| Ausstattung |
XXL, Schutzblech, Beleuchtung, Gepäckträger |
| Bremse hinten |
Magura MT5, 4-piston hydraulic disc, 180 mm rotor, Sport pads |
| Bremse vorne |
Magura MT5, 4-piston hydraulic disc, 180 mm rotor, Sport pads |
| Bremshebel |
Magura MT5 e-stop, hydraulic, with brake sensor |
| Cassette |
Shimano 11-36T, 10 spd |
| Display |
Bosch Purion, 4 mode selectable, walk assist |
| Farbe |
school bus yellow |
| Federweg vorne |
70 mm |
| Felgen |
Tern Atlas, ultra wide 36 mm, dual reinforced joint |
| Gabel |
Suntour custom for Tern, 1.5" tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE approved: 200 kg |
| Gepäckträger |
Frame integrated, heavy duty design |
| Glocke |
Pitch Plus, brass |
| Griffe |
Ergon |
| Hersteller/Marke |
Tern |
| Hinweis |
alle Maß- und Gewichtsangaben sind Circa-Werte |
| Kette |
10 spd, DHT for eBike, GST corrosion resistant coating |
| Kurbelgarnitur |
Tern GSD custom, forged 6061-AL DH crankarm |
| Ladegerät |
220V, 4A (EU); 100-240V, 4A (US) |
| Laufradgröße |
20 Zoll |
| Lenker |
Tern Sweep, 6061-AL, Tern Andros adapted |
| Modelljahr |
2024 |
| Motor Hersteller |
Bosch |
| Motor Leistung |
250 Watt |
| Motor Modell |
Bosch Cargo Line, 400% Assist, 85 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US) |
| Nabe hinten |
Tern Atlas, Boost Thru-Axle, Syntace X-12 standard, Cargo-optimized design |
| Nabe vorne |
Tern Atlas, Boost Thru-Axle, Cargo-optimized design, sealed cartridge bearing |
| Pedale |
Urban with non-slip surface, sealed bearings |
| Produktgewicht |
33,5000 kg |
| Rahmen |
Tern GSD, 6061-AL, patented MultiTruss design, EFBE Tri-Test approved: 200 kg |
| Rahmenmaterial |
Aluminium |
| Rahmentyp |
Lastenrad |
| Reifen hinten |
Tern x Schwalbe Super Moto-X, 62-406, Green Guard puncture protection, Reflex |
| Reifen vorne |
Schwalbe Big Ben Plus, 55-406, Green Guard puncture protection, Reflex |
| Rücklicht |
RearStop Brake Light, Always on brake light |
| Sattel |
Tern GSD by Velo, with rear handle |
| Sattelklemme |
Tern Collar, 6061-AL, 2pc |
| Sattelstütze |
Tern Telescope, 34.9/30.9 mm, 2014-AL |
| Schalthebel |
Shimano Deore, 1 x 10 spd |
| Schaltungsart |
10 Gang Kettenschaltung |
| Schaltwerk |
Shimano Deore Shadow+ |
| Schutzbleche |
Integrated Wheel Guard, AL6061, w/ Side Skirt |
| Speichen |
Stainless steel, 13G |
| Ständer |
Atlas Lockstand, w/ remote unlock, patented technology |
| Steuersatz |
Tern Flux Pro Taper, 1.5", angular contact bearings, Physis integrated |
| Vorbau |
Tern Andros, adjustable, forged construction, patented technology |
| Vorderlicht |
Tern Valo Direct, 190 lumens |
| Zulässiges Gesamtgewicht (kg) |
200 kg |
