| Akku |
TQ HPR, Bluetooth / ANT+ / Dedicated Smartphone app |
| Akku Hersteller |
TQ |
| Akku Kapazität in Wh |
360 Wh |
| Akku Montage |
Intube-Akku |
| Bremse hinten |
Shimano Deore M6120 4 Piston Disc |
| Bremse vorne |
Shimano Deore M6120 4 Piston Disc |
| Bremsscheibe |
V:Shimano SM-RT64 CL 180 mm // H:Shimano RT-EM600 CL 180 mm |
| Cassette |
Shimano CS-M6100 / 10-51 T |
| Dämpfer |
FOX NUDE 5T EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Custom large Air volume / DPS / Reb. Adj., Travel 130-90-Lockout / T165X45mm |
| Display |
TQ Internal 360Wh |
| Farbe |
Candy Yellow Flakes |
| Federweg vorne |
130 mm |
| Felgen |
V: Syncros X-30SE / 32H / 30mm, Tubeless ready // H: Syncros X-30SE / 32H / 30mm, Tubeless ready |
| Gabel |
FOX 34 Float Rhythm Air Grip, 3-Modes / Kabolt 15x110mm axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 130mm travel |
| Griffe |
Syncros Performance XC lock-on grips |
| Hersteller/Marke |
Scott |
| Hinweis |
alle Maß- und Gewichtsangaben sind Circa-Werte |
| Kette |
Shimano CN-M6100 |
| Kurbelgarnitur |
FSA Alloy crankset / 175mm / 34T |
| Ladegerät |
TQ 100-240V-4A |
| Laufradgröße |
29 Zoll |
| Lenker |
Syncros Fraser 2.0 DC Alloy 6061 D.B., mini Rise / back sweep 8° / 760mm |
| Modelljahr |
2023 |
| Motor Hersteller |
TQ |
| Motor Leistung |
250 Watt |
| Motor Modell |
TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph |
| Nabe hinten |
Formula CL-148M / 12x148mm / Micro Spline, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools |
| Nabe vorne |
Formula CL-811 / 15x110mm |
| Pedale |
NICHT im Lieferumfang enthalten |
| Produktgewicht |
17,6 kg |
| Rahmen |
Lumen eRIDE Carbon HMX, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline |
| Rahmenmaterial |
Carbon |
| Rahmentyp |
Fully |
| Reifen hinten |
Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Grip |
| Reifen vorne |
Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Soft |
| Sattel |
Syncros Tofino 1.5 Regular, Titanium rails |
| Sattelstütze |
Syncros Duncan Dropper Post 2.0, 31.6mm / S & M size 125mm / L size 150mm / XL size 170mm |
| Schalthebel |
Shimano Deore SL-M6100-IR / Rapidfire Plus, Ispec EV clamp |
| Schaltung |
Shimano XT RD-M8100 SGS, Shadow Plus / 12 Speed |
| Schaltungsart |
12 Gang Kettenschaltung |
| Speichen |
Stainless Black 15G / 1.8mm |
| Steuersatz |
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB |
| Vorbau |
Syncros DC 2.0, Syncros Cable Integration System, 0° rise / 6061 Alloy / 31.8mm / 1 1/8" |
