| Akku |
720 Wh Removable Integrated Li-Ion | 100% Charged in 3:55 (4A) / 7:35 (2A) | 80% Charged in 2:55 (4A) / 6:05 (2A) |
| Akku Hersteller |
Rocky Mountain |
| Akku Kapazität in Wh |
720 Wh |
| Akku Montage |
Intube-Akku |
| Ausstattung |
Keine Ausstattung |
| Bremse hinten |
Shimano XTR Trail 4 Piston | IceTec Metal Pads |
| Bremse vorne |
Shimano XTR Trail 4 Piston | IceTec Metal Pads |
| Bremshebel |
Shimano XTR |
| Cassette |
Shimano XTR 12s 10‐51T |
| Dämpfer |
Fox Float X Factory | Sealed Bearing Eyelet | 25x8mm F Hardware | All Sizes = 210x55mm |
| Display |
Rocky Mountain Jumbotron | Drive System Customization | Battery & Assist Level | Trip | Speed | |
| Farbe |
BLACK / BLUE |
| Federweg vorne |
150 mm |
| Felgen |
Race Face ARC Carbon 31 | 32H |
| Gabel |
Fox 36 Float EVOL GRIP2 Factory Series 150mm | 44mm Offset |
| Griffe |
ODI Elite Pro Lock On |
| Hersteller/Marke |
Rocky Mountain |
| Hinweis |
alle Maß- und Gewichtsangaben sind Circa-Werte |
| Kette |
Shimano M8100 |
| Kurbelgarnitur |
Race Face Carbon Cinch 34T | 30mm Spindle | Crank Length = 170mm |
| Laufradgröße |
29 Zoll |
| Lenker |
Race Face Next R | 780mm Width | 20mm Rise | 8° Backsweep | 4° Upsweep | 35mm Clamp |
| Modelljahr |
2023 |
| Motor Hersteller |
Rocky Mountain |
| Motor Leistung |
250 Watt |
| Motor Modell |
Dyname 4.0 Mountain Bike Drive | 250w Nominal Power | 108Nm | Rocky Mountain Micro Remote | Low RPM ‐ High Efficiency Classe 1 eMTB System | Designed in Canada |
| Nabe hinten |
DT Swiss Hybrid 350 Boost 148mm | 24T Star‐Ratchet |
| Nabe vorne |
Rocky Mountain Sealed Boost 15mm |
| Produktgewicht |
F: 203mm / R:203mm |
| Rahmen |
SMOOTHWALL™ Carbon. Integrated Display. Mid‐High Pivot Smoothlink Suspension System. Press Fit BB. RIDE‐4™ Adjustable Geometry + Suspension Rate. 140mm Travel. |
| Rahmenmaterial |
Carbon |
| Rahmentyp |
Fully |
| Reifen hinten |
Maxxis Minion DHR II 2.4 WT 3C MaxxTerra EXO+ Tubeless Ready |
| Reifen vorne |
Maxxis Minion DHF 2.5 WT 3C MaxxTerra EXO+ Tubeless Ready |
| Sattel |
SDG Bel Air 3.0 Lux |
| Sattelstütze |
Fox Transfer Factory Series 30.9mm | SM = 125mm | MD = 150mm | LG = 175mm | XL = 200mm |
| Schalthebel |
Shimano XTR |
| Schaltung |
Shimano XTR |
| Schaltungsart |
12 Gang Kettenschaltung |
| Schaltwerk |
Shimano XTR |
| Speichen |
F : DT Swiss Champion 2.0 | R : DT Swiss Alpine 2.3/2.0 |
| Steuersatz |
FSA Orbit NO.57E | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
| Vorbau |
Rocky Mountain 35 CNC | 0° Rise | All Sizes = 40m |
