| Akku |
720 Wh Removable Integrated Li-Ion |
| Akku Hersteller |
Rocky Mountain |
| Akku Kapazität in Wh |
720 Wh |
| Akku Montage |
Intube-Akku |
| Ausstattung |
Keine Ausstattung |
| Bremse hinten |
Shimano XT Trail 4 Piston | Metal Pads |
| Bremse vorne |
Shimano XT Trail 4 Piston | Metal Pads |
| Cassette |
Shimano Deore 10‐51T 12spd |
| Dämpfer |
Fox Float X Performance | Sealed Bearing Eyelet | 25x8mm F Hardware |
| Display |
Rocky Mountain Jumbotron | Drive System Customization | Battery & Assist Level | Trip | Speed | Cadence | Top Tube Integration |
| Farbe |
Black/ Red |
| Federweg vorne |
170 MM |
| Felgen |
WTB ST i30 TCS 2.0 Tubeless | 32H |
| Gabel |
Fox 38 Float EVOL GRIP Performance Series 170mm | 44mm Offset |
| Griffe |
ODI Elite Pro Lock On |
| Hersteller/Marke |
Rocky Mountain |
| Hinweis |
alle Maß- und Gewichtsangaben sind Circa-Werte |
| Kette |
Shimano M6100 |
| Kurbelgarnitur |
Race Face Aeffect Cinch 34T |
| Ladegerät |
Rocky Mountain Powerplay FAST Charger | 4A | 48V |
| Laufradgröße |
29 Zoll |
| Lenker |
Rocky Mountain AM | 780mm Width | 38mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp |
| Modelljahr |
2023 |
| Motor Hersteller |
Dyname |
| Motor Modell |
Dyname 4.0 Mountain Bike Drive | 250w Nominal Power | 108Nm | Rocky Mountain Micro Remote | Low RPM ‐ High Efficiency Classe 1 eMTB System |
| Nabe hinten |
DT Swiss Hybrid 370 Boost 148mm | 24T Star‐Ratchet |
| Nabe vorne |
Rocky Mountain Sealed Boost 15mm |
| Pedale |
NICHT im Lieferumfang enthalten |
| Rahmen |
FORM™ Alloy. Integrated Display. Mid‐High Pivot Smoothlink Suspension System. Press Fit BB. RIDE‐ 4™ Adjustable Geometry + Suspension Rate. 160mm Travel. |
| Rahmenmaterial |
Aluminium |
| Rahmentyp |
Fully |
| Reifen hinten |
Maxxis Minion DHR II 2.4 WT 3C MaxxTerra DD Tubeless Ready |
| Reifen vorne |
Maxxis Assegai 2.5 WT 3C MaxxGrip DD Tubeless Ready |
| Sattel |
SDG Bel Air 3.0 Lux |
| Sattelstütze |
Race Face Aeffect R Dropper 30.9mm | Shimano MT500 Remote |
| Schalthebel |
Shimano XT |
| Schaltung |
Shimano XT |
| Schaltungsart |
12 Gang Kettenschaltung |
| Schaltwerk |
Shimano XT |
| Speichen |
F: DT Swiss Champion 2.0 | R: DT Swiss Alpine 2.3/2.0 |
| Steuersatz |
FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
| Vorbau |
Rocky Mountain 35 AM | 5° Rise |
