| Akku |
Bosch Powertube 625Wh |
| Akku Hersteller |
Bosch |
| Akku Kapazität in Wh |
625 Wh |
| Akku Montage |
Intube-Akku |
| Ausstattung |
Keine Ausstattung |
| Bremse hinten |
Sram DB8 |
| Bremse vorne |
Sram DB8 |
| Bremshebel |
Sram DB8 |
| Bremsscheibe |
200 mm / 200 mm |
| Cassette |
Sram PG-1210, 11-50T, 12s |
| Dämpfer |
RockShox Deluxe Select R DebonAir, 205x65mm. Settings: Low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings |
| Display |
Bosch Kiox 300 / Bosch Led Remote |
| Farbe |
Blue Marlin/ Black |
| Federweg vorne |
160 mm |
| Felgen |
MDK-HP1 29, 30mm internal width, tubeless ready, 32 spokes |
| Gabel |
RockShox 35 Silver TK 29, 160mm, TurnKey, Solo Air, tapered steerer tube, Boost 15x110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload |
| Griffe |
Onoff Twin, 1lock-on, 135mm |
| Hersteller/Marke |
Mondraker |
| Hinweis |
alle Maß- und Gewichtsangaben sind Circa-Werte |
| Kette |
Sram SX Eagle, 12s, Powerlock |
| Kurbelgarnitur |
Race Face Aeffect ebike, 165mm |
| Laufradgröße |
29 Zoll |
| Lenker |
Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9° backsweep, 5° upsweep, 31.8mm barbore |
| Modelljahr |
2023 |
| Motor Hersteller |
Bosch |
| Motor Leistung |
250 Watt |
| Motor Modell |
Bosch Performance Line CX Cruise (25Km/h) GEN4 Smart System |
| Nabe hinten |
Formula EHL148 Boost 12x148mm, sealed bearings, IS 6 bolts |
| Nabe vorne |
Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts |
| Pedale |
NICHT im Lieferumfang enthalten |
| Produktgewicht |
25,2 kg |
| Rahmen |
Chaser 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel |
| Rahmenmaterial |
Aluminium |
| Rahmentyp |
Fully |
| Reifen hinten |
Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead |
| Reifen vorne |
Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead |
| Sattel |
MDK ebike black |
| Sattelstütze |
Onoff Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm |
| Schalthebel |
Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click |
| Schaltung |
Sram SX Eagle |
| Schaltungsart |
12 Gang Kettenschaltung |
| Schaltwerk |
Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1 |
| Speichen |
CN round stainless steel |
| Steuersatz |
Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45°x45°, bottom 51.9x40x8x45°x45° |
| Vorbau |
Onoff Sulfur FG 30mm 0°, 6061 forged alloy, 31.8mm barbore |
